INDIVIDUAL
4-WAY STEEL PARALLELS

PROUDLY MADE IN OUR FACILITY IN THE U.S.A.



P-06050100, P-06050075, P-06025075 & P-06025050 Individual 4-Way Steel Parallels
P-06050100, P-06050075, P-06025075 & P-06025050

  • These hardened steel parallels are ground to such close tolerances on four sides that there is no need to buy matched pairs for many common uses.


  • Can be used individually or matched with any other individual 4-way parallel at any time.


  • Different sizes can be used together. For example a 6" x 1/2" x 1" can be used with a 8" x 3/4" x 1" on the 1" dimension.


  • Held to size 0.00025" on four sides.


  • Adjacent sides square within 0.0005" per inch.


  • Opposite sides parallel within 0.0001" per 6 inches.


MODEL # LENGTH WIDTH HEIGHT WT(#)
P-06025038 6" 1/4" 3/8" 1
P-06025050 1/2"
P-06025063 5/8"
P-06025075 3/4"
P-06025100 1"
P-06038050 3/8" 1/2"
P-06038063 5/8"
P-06038075 3/4"
P-06050063 1/2" 5/8"
P-06050075 3/4"
P-06050100 1" 2
P-08050100 8"
P-08075100 3/4" 3
P-08075125 1-1/4"
P-12075100 12" 1" 4
P-12100150 1" 1-1/2" 6
P-12100200 2" 8
P-12150200 1-1/2" 11
P-12150300 3" 16
