ELECTROMAGNETIC SURFACE GRINDER CHUCKS

PROUDLY MADE IN OUR FACILITY IN THE U.S.A.


EMCB-618-L





  • Top plate has 1/8" steel poles and 1/16" stainless steel separators.

  • Chucks are completely sealed against dirt and liquids and can be used on EDM machines.

  • Longitudinal (lengthwise) or transverse (crosswise) pole models available.

  • Two clamps, back rail and side rail included.

  • Chuck controls must be used with all electromagnetic chucks!



TRANSVERSE POLES


MODEL # LENGTH WIDTH HEIGHT WATTS WT(#)
EMCB-612-T 12" 6" 3-1/2" 72 75
EMCB-618-T 18" 130 117
EMCB-815-T 15" 8" 125 132
EMCB-818-T 18" 150 160
EMCB-824-T 24" 220 210
EMCB-1015-T 15" 10" 160 165
EMCB-1024-T 24" 240 255
EMCB-1036-T 36" 350 370
EMCB-1216-T 16" 12" 200 200
EMCB-1218-T 18" 225 225
EMCB-1224-T 124" 280 310
EMCB-1230-T 30" 390 371

EMCB-1236-T

36" 430 442


LONGITUDINAL POLES


MODEL # LENGTH WIDTH HEIGHT WATTS WT(#)
EMCB-612-L 12" 6" 3-1/4" 56 75
EMCB-618-L 18" 110 117
EMCB-815-L 15" 8" 85 132
EMCB-818-L 18" 100 160
EMCB-824-L 24" 150 210
EMCB-1015-L 15" 10" 100 165
EMCB-1024-L 24" 180 255
EMCB-1036-L 36" 260 370
EMCB-1216-L 16" 12" 135 200
EMCB-1218-L 18" 150 225
EMCB-1224-L 124" 200 310
EMCB-1230-L 30" 250 371

EMCB-1236-L

36" 300 442



!!!!!     FOR IMPORTANT HOLDING POWER INFORMATION CLICK HERE     !!!!!






Automation and Metrology 130 Liberty Street Painesville, Ohio 44077
Phone:  (440) 354 6436  Fax:  (440) 639 9983
E-mail: sales@auto-met.com

Back


SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
