SUBURBAN TOOL
PRECISION GROUND STEEL ANGLE
PLATES
|
PROUDLY MADE IN OUR FACILITY IN
THE U.S.A.
- Solid, one-piece
angle plates are made from hardened steel.
- AP-443-H & AP-443-NH
are square and parallel within 0.0001". All other models are held
to 0.0002".
- AP-443-NH has no
holes. All others are furnished with tapped holes.
- SineSet®
models are made to bolt directly to sine plates and compound sine
plates of the same series.
|
MODEL # |
SineSet®
SERIES |
LENGTH |
WIDTH |
HEIGHT |
THICKNESS |
TAPPED
HOLES |
WT(#) |
|
SINGLE |
PAIR |
SINGLE |
PAIR |
|
SineSet® COMPATIBLE |
| AP-334-S0 |
AP-334-M-S0 |
S0 |
4" |
3" |
3" |
1" |
(13) 1/4-20
(4) 5/16" x 7/16" C'BORE |
6 |
11 |
| AP-444-S1 |
AP-444-M-S1 |
S1 |
4" |
4" |
1-1/4" |
(13) 1/4-20
(4) 5/16" x 7/16" C'BORE |
10 |
19 |
| AP-446-S2 |
AP-446-M-S2 |
S2 |
6" |
(14) 3/8-16
(4) 7/16" X 5/8" C'BORE |
14 |
27 |
| AP-664-S1 |
AP-664-M-S1 |
6" |
(33) 1/4-20
(6) 5/16" x 7/16" C'BORE |
20 |
39 |
|
NOT
SineSet® COMPATIBLE |
| AP-333 |
AP-333-M |
-- |
3" |
3" |
3" |
1" (1/2" STEP) |
(24) 1/4-20 |
5 |
9 |
| AP-443-H |
-- |
4" |
4" |
1-1/8" |
(31) 1/4-20
(2) 13/32" X 19/32 C'BORE |
9 |
n/a |
| AP-443-NH |
AP-443-NHM |
-- |
9 |
17 |
|
|
|
