We Offer Ring Gages, Plug Gages, Pin Gages, Fast Delivery For ACME Gauges, Cylindrical Gages, Setting Rings, Class ZZ Pin Gages

Whether you need English or metric metrology instruments; a single gage or gage set, GSG gage VTG provides for all of your guage needs.  If you are looking for a pin gage, plug gage, thread gage  ring gage, trilock gage or taperlock gage, English gage set or metric gage set, look no further. We offer competitive quotes from major gage manufactures: Vermont thread gage, Glastonbury gage, Greenfield gage, Myer gage, Deltronic and others, feel confident that we will get the best price and the best delivery, we understand these manufactures capabilities and this helps you.

Vermont Gage    Glastonbury Gage    Greenfield Gages     PMC Gage    Southern Gage

For top quality inspection instruments, demand the best American made gages, request Vermont gage and Vermont thread gage fixed limit gages.

VT gage also has NPT and NPTF pipe plug gages, thread ring gages and full calibration service, NIST traceable. Fully ISO 9001:2000 Certified, quality is assured. Use our live chat for a quick quote for your chrome gage, steel gage or new black guard gage needs in pin, plug, ring, pipe, taperlock, trilock and reversible gages.
Visit our online catalog for gage sets, custom library sets, thread measuring wires, GO/NoGo assembly, drill blanks, custom gages and all of your quality metrology requirements. Call our technical support department for answers to your gage (guage) questions. Metrology technical information is just one of the services provided by our gage support team.
The archive of gage technical support contains past articles and technical bulletins as well as answers to customer questions. Need a gage set or gage library? From class XX to class ZZ, plug gage, pin gage thread gage ring gage, all fixed limit gages, measuring gages and inspection gages are available or can be custom made.

          - Custom Gage Manufacturing Available -


Maximum Product Size:
Minimum Product Size:

Calculation Results

Total Product Tolerance:
Calculated Gage Tolerance:
Suggested Gage Tolerance:

*Parameters and results are rounded to 8 decimal places.
*Suggested gage tolerance is calculated using the 10% product tolerance rule.

Diameter Tolerance Chart Reference (ANSI/ASME B89.1.5)

Diameter Range
0.010" - 0.825" 0.000010" 0.000020" 0.000040" 0.000070" 0.000100" 0.00020"
0.825" - 1.510" 0.000015" 0.000030" 0.000060" 0.000090" 0.000120" 0.00024"
1.510" - 2.510" 0.000020" 0.000040" 0.000080" 0.000120" 0.000160" 0.00032"
2.510" - 4.510" 0.000025" 0.000050" 0.000100" 0.000150" 0.000200" 0.00040"
4.510" - 6.510" 0.000033" 0.000065" 0.000130" 0.000190" 0.000250" 0.00050"
6.510" - 9.010" 0.000040" 0.000080" 0.000160" 0.000240" 0.000320" 0.00064"
9.010" - 12.010" 0.000050" 0.000100" 0.000200" 0.000300" 0.000400" 0.00080"
