Incremental length gauges from
HEIDENHAIN offer high accuracy over long measuring ranges. These
sturdily made gauges are available in application-oriented
versions.
They have a wide range of applications in production metrology,
in multipoint inspection stations, measuring equipment
monitoring, and as position measuring devices.
|
|
|
Search Result:
|
Type |
Incremental signals |
Recommended measuring step |
System
accuracy
(at 19 to 21 °C) |
Measuring range [mm]
|
PDF INFO
|
|
HEIDENHAIN-METRO MT 1201 |
11 µASS |
0,1 µm/0,05 µm |
± 0,2 µm |
1 |
mounting instructions |
|
HEIDENHAIN-METRO MT 1271 |
TTL |
0,1 µm |
± 0,2 µm |
12 |
mounting instructions |
|
HEIDENHAIN-METRO MT 1281 |
1 VSS |
0,1 µm/0,05 µm |
± 0,2 µm |
12 |
mounting instructions |
|
HEIDENHAIN-METRO MT 1287 |
1 VSS |
0,1 µm/0,05 µm |
± 0,2 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1208 |
11 µASS |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1278 |
TTL |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1288 |
1 VSS |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1207 |
11 µASS |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1277
|
TTL |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 1287 |
1 VSS |
1 µm/0.5 µm |
± 1 µm |
12 |
mounting instructions |
|
HEIDENHAIN-CERTO CT 2501 |
11 µASS |
0,1 µm/0,05 µm |
± 0.1 µm without compensation;
± 0.03 µm after linear length error compensation |
25 |
|
|
HEIDENHAIN-CERTO CT 2502 |
11 µASS |
|
± 0.1 µm without compensation;
± 0.03 µm after linear length error compensation |
25 |
|
|
HEIDENHAIN-METRO MT 2501 |
11 µASS |
0,1 µm/0,05 µm |
± 0,2 µm |
25 |
mounting instructions |
|
HEIDENHAIN-METRO MT 2571 |
TTL |
0,1 µm/0,05 µm |
± 0,2 µm |
25 |
mounting instructions |
|
HEIDENHAIN-METRO MT 2581 |
1 VSS |
0,1 µm/0,05 µm |
± 0,2 µm |
25 |
mounting instructions |
|
HEIDENHAIN-METRO MT 2587 |
1 VSS |
0,1 µm/0,05 µm |
± 0,2 µm |
25 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3008 |
11 µASS |
1 µm/0.5 µm |
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3078 |
TTL |
1 µm/0.5 µm |
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3088 |
1 VSS |
1 µm/0.5 µm |
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3007 |
11 µASS |
|
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3077 |
TTL |
1 µm/0.5 µm |
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-SPECTO ST 3087 |
1 VSS |
1 µm/0.5 µm |
± 1 µm |
30 |
mounting instructions |
|
HEIDENHAIN-CERTO CT 6001 |
11 µASS |
|
± 0.1 µm without compensation;
± 0.05 µm after linear length error compensation |
60 |
|
|
HEIDENHAIN-CERTO CT 6002 |
11 µASS |
|
± 0.1 µm without compensation;
± 0.05 µm after linear length error compensation |
60 |
|
|
HEIDENHAIN-METRO MT 60M |
11 µASS |
|
± 0,5 µm |
60 |
|
|
HEIDENHAIN-METRO MT 60K |
11 µASS |
|
± 0,5 µm |
60 |
|
|
HEIDENHAIN-METRO MT 101M |
11 µASS |
|
± 1 µm |
100 |
|
|
HEIDENHAIN-METRO MT 101K |
11 µASS |
|
± 1 µm |
100 |
|
|
|
|
|
|
