HEIDENHAIN ERN 1080 Incremental Rotary Encoder
Key specifications
- Incremental rotary encoder with integral bearing
- Blind hollow shaft Ø 6 mm; stator coupling for plane surface
- ~ 1 Vpp interface (DC 5 V ±0.5 V); cutoff frequency ≥ 180 kHz
- Line counts 100 to 3600
- One reference mark
- System accuracy 1/20 of grating period
- Max. speed 12,000 rpm
- High axial tolerance of up to ±0.5 mm
- Housing diameter ≈ 35 mm
- Protection IP64; approx. 0.1 kg
- Max. operating temperature 100 °C
Download current ERN 1000 specifications (May 2026, PDF)
Pricing and lead times on request. Use Request a Quote and include the model, line count, and interface (current ID 534913-xx).
