Model A-10

  Model B-10      B-20          B-40

  Model E-10      E-20          E-40

  Model F-10       F-20

  Model G1-10     G1-20      G1-40     G2-10      G2-20     G2-40

  Model H-10       H-20        HL-10      HL-20

  Model JSLP      JLP          J-10        J-20         J-40

  Model K1-10     K1-20       K1-40      K2-10      K2-20     K2-40

  Model KK1-10   KK1-20     KK1-40    KK2-10   KK2-20   KK2-40

  Model LG-10     LG-20       LGM-10   LGM-20






How to Calibrate this Gage









Concentricity Gaging Systems A-10

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 3” (76mm)
Gage Length: 8.5” (216mm)
Gage Width: 4.5” (114mm)
Shipping Weight: 4.5lb. (2.0kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual




Concentricity Gaging Systems B-10

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 4” (102mm)
Gage Length: 10.5” (267mm)
Gage Width: 4.5” (114mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break DownMain Roller Selection Gage Manual




Concentricity Gaging Systems B-20

Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 6” (152mm)
Gage Length: 12.5” (318mm)
Gage Width: 4.5” (114mm)
Shipping Weight: 6.4lb. (2.9kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual




Concentricity Gaging Systems B-40

Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to 8” (203mm)
Gage Length: 14.5” (368mm)
Gage Width: 6” (152mm)
Shipping Weight: 11.2lb. (5.1kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual






E-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

E-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 6.4lb. (2.9kg.)

Gage SpecificationsParts Break Down

E-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to a 8” (203mm)
Shipping Weight: 11.2lb. (5.1kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual











F-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

F-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 6.4lb. (2.9kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual


















G1-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

G1-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 6.4lb. (2.9kg.)

Gage SpecificationsParts Break Down

G1-40 Model

Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to a 8” (203mm)
Shipping Weight: 11.2lb. (5.1kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual


















G2-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

G2-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 6.4lb. (2.9kg.)

Gage SpecificationsParts Break Down

G2-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to a 8” (203mm)
Shipping Weight: 11.2lb. (5.1kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual










H-10 Model
Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 12” (305mm)
Shipping Weight: 7.5 lb. (3.4kg.)

Gage SpecificationsParts Break Down

H-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 12” (305mm)
Shipping Weight: 8.5lb. (3.9kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual











HL-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 30” (762mm)
Shipping Weight: 24.5lb. (11.1kg.)

Gage SpecificationsParts Break Down

HL-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 30” (762mm)
Shipping Weight: 26.5lb. (12kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual






JLS-10, JLP-10, J-10 Models

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 4.5lb. (2.2kg.)

Gage SpecificationsParts Break Down

J-20 Model

Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 4.4lb. (2.0kg.)

Gage SpecificationsParts Break Down

J-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to a 8” (203mm)
Shipping Weight: 9.2lb. (4.2kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual







K1-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to a 4” (102mm)
Shipping Weight: 11.5lb. (5.2kg.)

Gage SpecificationsParts Break Down

K1-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 14.8lb. (6.8kg.)

Gage SpecificationsParts Break Down

K1-40 Model

Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to a 8” (203mm)
Shipping Weight: 11.5lb. (5.2kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual
















K2-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

K2-20 Model
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 6” (152mm)
Shipping Weight: 14.8lb. (6.8kg.)

Gage SpecificationsParts Break Down

K2-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to 8” (203mm)
Shipping Weight: 18.5lb. (8.4kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual







KK1-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

KK1-20 Model

Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 6” (152mm)
Shipping Weight: 14.8lb. (6.8kg.)

Gage SpecificationsParts Break Down

KK1-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to 8” (203mm)
Shipping Weight: 18.5lb. (8.4kg.)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual






KK2-10 Model

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 4” (102mm)
Shipping Weight: 4.9lb. (2.2kg.)

Gage SpecificationsParts Break Down

KK2-20 Model

Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to 6” (152mm)
Shipping Weight: 14.8lb. (6.8kg.)

Gage SpecificationsParts Break Down

KK2-40 Model
Part Diameters: 3/4” to 4” (20mm to 102mm)
Part Lengths: Up to 8” (203mm)
Shipping Weight: 18.5lb. (8.4kg.)
(Optional Motorized Drive Unit Shown)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual











LG-10, LGM-10 Models

Part Diameters: 1/8” to 1” (3mm to 25mm)
Part Lengths: Up to 6” (152mm)
Shipping Weight: 3.5lb. (1.6kg.)

Gage SpecificationsParts Break Down

LG-20, LGM-20 Models
Part Diameters: 3/8” to 2” (10mm to 50mm)
Part Lengths: Up to a 6” (152mm)
Shipping Weight: 4.4lb. (2.0kg.)
(Optional Stepping Motorized Drive Unit Available)

Gage SpecificationsParts Break DownMain Roller SelectionGage Manual


How to Calibrate this Gage
