HEIDENHAIN ACANTO Series Length Gauge
Key specifications
- High system accuracy: ±2 µm / ±1 µm
- Serial data transmission
- Interface: EnDat 2.2
- Protection rating of up to IP67
- Compact design for limited installation space
- Various plunger actuation possibilities
- Absolute length gauge with EnDat interface
Models: AT 1217 (12 mm, ±1 µm, pneumatic), AT 1218 (12 mm, ±1 µm, workpiece-actuated), AT 3017 (30 mm, ±2 µm, pneumatic), AT 3018 (30 mm, ±2 µm, workpiece-actuated). Check measuring range and actuation when requesting a quote.
Pricing and lead times on request. Use Request a Quote and include measuring length, interface, and accuracy grade.
