HEIDENHAIN Measuring Contacts for Length Gauges
Key specifications
- Incremental length gauges
- System accuracy: ±1 µm / ±0.5 µm / ±0.2 µm
- Measuring range of up to 100 mm
- High repeatability
- Version with low measuring forces
- Incremental length gauges
- Interchangeable M2.5 measuring contacts for HEIDENHAIN length gauges
- Ball-type: steel (ID 202504-01), carbide (202504-02), ruby (202504-03)
- Domed, carbide (229232-01); flat, steel (270922-01) or carbide (202506-01)
- Pin-type, steel (202505-01); knife-edge, steel (202503-01)
- Roller contacts, steel: crowned (202502-03), cylindrical (202502-04)
- Adjustable contacts, carbide: flat (202507-01), knife-edged (202508-01)
Pricing and lead times on request. Use Request a Quote and include the model and HEIDENHAIN ID number if you have it.
