HEIDENHAIN CERTO Series Length Gauge
Key specifications
- Interferential scanning principle
- Very high system accuracy of down to ±0.03 µm
- Well-matched ball-bearing guide for very high quality
- Defined thermal behavior
- Large measuring ranges of up to 60 mm
- Interface: 11 µAPP
- Incremental length gauge
- Interferential scanning for exceptional accuracy
- System accuracy down to ±0.03 µm
Models: CT 2501 and CT 6001 (motorized plunger, 25 mm and 60 mm measuring ranges); CT 2502 and CT 6002 (plunger coupled to the moving machine part, 25 mm and 60 mm). All use the 11 µAPP interface. Specify the exact model and application when requesting a quote.
Pricing and lead times on request. Use Request a Quote and include measuring length, interface, and accuracy grade.
